Clad Hidden Sash

A concealed sash outside. Natural timber within.

Inside
Natural timber
Outside
Aluminum cladding

Completed home with Clad Hidden Sash fixed glazing and French doors. Manufacturer reference installation - not a Windows Guy project.


Product references

Muntins for timber & aluminum-clad timber

Explore divided-light details for Timber Classic, Timber Estate, the Clad Classic and Square bars and Clad Hidden Sash. Each drawing shows the detail for the named profile; I confirm the layout and finish for your project.

Clad Hidden Sash bar muntin section drawingView full image
Clad Hidden Sash bar - muntin detail from the system provider. Original metric dimensions; drawing not to scale.

Selecting this family for a Canadian project

For aluminum-clad wood, specify the timber interior, exterior cover, glazing and maintenance requirements. The estimator is a preliminary budget; the assembly needs a reviewed quote. Provider catalogue figures describe particular configurations. Confirm the whole-unit result, rating method and available documents for your sizes with your local designer and building official.

U-factor figures use imperial Btu/(h ft2 F) unless another unit is stated; metric values use W/(m2 K). Uf describes the frame, Ug the glass, and Uw the whole window. SHGC and ER are dimensionless. Converting units does not establish certification or Canadian code acceptance.

Canadian orders use DAP to the agreed named place, with the Canadian buyer as importer of record. Import charges, unloading and local installation need their own confirmed scope. Site access and remote delivery require individual review.

Overview

What makes the Clad Hidden Sash
stand out.

Clad Hidden Sash pairs a timber interior with aluminum exterior protection and a concealed-sash design. From outside, the opening sash sits behind the frame, creating a restrained outline beside fixed glazing. Inside, real wood adds warmth to the room. Concealed hinges support the clean appearance of the window. I will review the exact window arrangement, finish and glazing with you so the design works across the whole elevation.

See how aluclad compares in my aluclad vs aluminum vs wood guide.

Key Highlights

  • Concealed opening sash for a quieter exterior.
  • Natural timber interior and aluminum outer covering.
  • Concealed hinges for a clean interior detail.
✓

Ideal For

Contemporary custom homes where consistent frame lines and natural interior materials matter.

↔

Consider an Alternative When

The hidden-sash detail needs careful coordination with fixed windows and adjacent doors. A matching appearance does not mean every assembly uses identical sections.

Technical specifications

System depth

3.21 in. / 3.60 in. (81.5 / 91.5 mm)

Tilt-turn visible frame and sash

Approx. 3.54 in. (90 mm)

Glazing

Double or triple pane; XL glass up to 2.28 in. (58 mm)

Sealing

3 sealing lines

Concealed window hardware

Maco Multi Power; published sash capacity up to 331 lb (150 kg)

Tilt-turn height - catalogue reference

Up to 9 ft 2 in. (2,800 mm), without a dividing mullion; selected configurations

Timber construction and spacer

Three-layer timber; Chromatech or Multitech warm-edge spacer

U-Factor - US catalogue reference

From 0.16 Btu/(h ft2 F)Units: 0.91 W/(m2 K), in the same order. Unit conversion, not a separate rating.

Solar and daylight - US catalogue

SHGC 0.15-0.25; VT 0.29-0.43

Acoustics - European reference

Rw up to 48 dB; not an STC or OITC rating

Interior wood

Pine, oak, meranti, larch or spruce

US catalogue thermal and solar values describe selected configurations. Obtain the applicable product report and glass specification for your order; these are not a project certification.

Published dimensions and sash loads are configuration limits, not a guaranteed combination. Visible frame width is separate from system depth.

European Rw and RC2 classifications cannot be substituted for US acoustic, impact or structural ratings.

Options for your project

Window arrangement

Fixed and tilt-turn windows, combined units and corner glazing can be coordinated with the related sliding-door family.

Glazing and security

Specify the glass for energy, noise and safety requirements. Decorative glass, muntins and RC2 security configurations are available for review.

Timber finish

Transparent finishes or RAL/NCS colors; custom color matching can be reviewed against a physical sample.

Aluminum exterior

Select the exterior RAL color and matte or textured surface independently of the wood interior.

Slim connections

Published movable mullion: 3.82 in. (97 mm); fixed mullion: 3.94 in. (100 mm). Confirm the actual joint detail in shop drawings.

From this system to your opening schedule

Review the opening type, dimensions, glazing, finish and installation interface together. Provider references describe a system family; the documents for your project need to match the proposed assembly and local requirements.

The selection sheet frames the choices and questions to confirm. Dimensioned installation details and assembly-specific rating evidence are checked for your drawings.

Get Clad Hidden Sash for your project

Send your window schedule and I'll have a budget estimate back to you the same or next working day.
